Features

  • Economically easy to install.
  • Uniformity of water fidtribution very high even in windy conditions.
  • Long Life Product made of high Quality engineering Plastic.
  • Designed to ensure no damage to crop.

Specification

  • Arm, Body, Nozzles & Bearing of Derlin Materialfor Long Life.
  • Trajectory Angle 23 degree.
  • Lockable Design of nozzles for cleaning the sprinker.
  • Stainless Steel Pin & Spring.

Application

Agriculture, Horticulture, Golf course, Wheat & Vegetables etc. Odeal for most solid set Portable application.

Performance Chart

Main Nozzle Spreader Nozzle Pressure in Kg/Cm2 Diameter in Meter Discharge in LPM Spacing (m)
Sprinkled Area
5.1 3.1 1 21 23 12 X 12 144
5.1 3.1 2 24 30 12 X 12 144
5.1 3.1 3 28 37 12 X 12 144

* Performance is based on ideal confitions of Temperature, Wind Velocity and Humidity

(A) Standard Nozzle Size
